Vieworks VIVIX-S 1717NBW Wireless Flat Panel Detector System

• 17”x17” Flat Panel Gadox Scintillator Detector, Wireless, with System Control Unit (SCU) / FXRS-04A
• Battery charger x 1 & battery pack x 4
• Image processing viewer software (VXvue) installed on ‘to spec’ PC
• Standard Digital Monitor (22”)

Techincal Specifications

• Technology -                        a-Si TFT
• Scintillator -                          Csl/Gadox
• Pixel Pitch -                          140um
• Spatial Resolution -              3.5lP/mm
• Pixels-                                  3,072 x 3,072 pixels
• Image Size-                         17" x 17" (43.0cm x 43.0cm)
• Grayscale-                           16 bit
• Recommened cycle time-    15 s
• Energy Range-                    40-150kV
• X-Ray Generator Interface- Line trigger:DR trigger Mode   Auto triger: AED mode
• Data Interface-                     Gigabit Ethernet (1000BASE-T)
• Image Acquisition-               3 Sec
• Dimensions-                         46.0cm x 46.0cm x 1.5cm
• Weight-                                 4.5 kg
• Battery -                                Lithium Ion 3100 mAh x2    6 hours (capturing)
• Dust and Water Resistant-   IP53
• X-ray Voltage range-            40 - 150 KVp
• Operating Environment-       10c - 35c, 30-85% RH (non-condensing)
• Power Consumption-            DC 24 V, 1.0 A
