Vieworks VIVIX-S 1717VB Wired Flat Panel Detector System
Out of stock
- 17" x 17 fixed cassette size tethered panel
- Stable and reliable AED (Automatic Exposure Detection)
- Fast booting time: 15 seconds
- Robust mechanical structure
- 16 bit analog-to-digital conversion
Details
Includes
- 17”x17” Flat Panel Gadox Scintillator Detector, Wired, with IO BOX (Power Supply)
- Image processing viewer software (VXvue) installed on ‘to spec’ PC
- Standard Digital Monitor (22”)
Features
- 17" x 17 fixed cassette size tethered panel
- Stable and reliable AED (Automatic Exposure Detection
- Fast booting time: 15 seconds
- Robust mechanical structure
- 16 bit analog-to-digital conversion
Techincal Specifications
- Technology - a-Si TFT with PIN diode
- Scintillator - Gd202S:Tb
- Pixel Pitch - 140um
- Spatial Resolution - 3.5lP/mm
- Pixels- 3,072 x 3,072 pixels
- Image Size- 430.08mm x 430.08mm
- Grayscale- 16 bit
- Energy Range- 40-150kV
- X-Ray Generator Interface- Automatic Exposure Detection, External Line Trigger
- Data Interface- Gigabit Ethernet (1000BASE-T)
- Image Acquisition- 2 Sec
- Dimensions- 460mm x 460mm x15.5mm
- Weight- 4.5 kg
- Operating Environment- 10c - 35c, 30-85% RH (non-condensing)
